Features of SMART Vat Pasteurizer (VDP)
- Accepts raw milk;
- Cools milk to 4°C;
- Stores raw milk;
- Pasteurizes raw milk;
- Matures the milk;
- Cools pasteurized milk to 4°C;
- Stores pasteurized milk;
- Dispatches pasteurized milk;
- Sets and adjusts temperature modes for technological processes;
- Automatically flushes reservoirs;
- Mixes products;
- Adjusts the rate of mixing products;
- Removable stirrers, depending on the product;
- Sustains constant temperature of the product;
- Yields depending on the product (040,050, 0100);
- Combined heating (electricity, steam);
- Execution of preset formulations.
SMART Vat Pasteurizer produces
Ayran
Pasteurized milk
Soft cheeses
Matzoon
Fermented milk products (kefir, ryazhenka, prostokvasha, varenets, etc.);
Cheddar-type cheeses
Cottage cheese
Yougurts
Semi-hard cheeses
Pasteurization, cooling, maturing, and ripening of cream for sour cream production
Pasteurization, cooling, and ripening of cream for butter production
Pasteurization of substandard milk for feeding calves
The equipment supersedes
Pump – 1 pce (50% economy);
Piping manifold (taps, couplings, fittings, fasteners) (90% economy);
Electric cables (90% economy);
Control panels with automated tools (35% economy);
Pipeline washing (60% economy);
Running water consumption (80% economy);
Manual labor (70% economy);
Milk loss (95% reduction);
Operation space (70% economy);
Time (50% economy).
Heating
Formulation for specific products
Cooling
Dispatching work through remote access
Flushing
Setting up of a local network at the enterprise
Water supply and discharge
Stirrer operation
Technical specifications of SMART Vat Pasteurizer
Basic set
| VAT TYPE | |||
|---|---|---|---|
| Name of parameters | VDPU 0,2 | VDPU 0,6 |
VDPU 1,0 |
| Working capacity, L | 200 | 600 | 1000 |
| Installed average cooling capacity, kW | 4 | 10 | 14 |
| Stirrer rotation rate, adjustable, rpm | 2-14 | ||
| Refrigerant | R-404A | ||
| Product heating time up to 65°С, no more than, h | 3 | 3 | 3 |
| Number of heating elements, pcs. | 3 | 3 | 4 |
| Heating elements power, kW | 9 | 9 | 9 |
| Heating elements installed power, kW | 27 | 27 | 36 |
| Unit dimensions: L*W*H | 2645*1280*1210 | 2980*1710*1210 | 1970*1710*1550 |
| Unit weight, not more than, kg | 500 | 700 | 740 |
